It has excellent adhesive strength on various materials and also it has excellent chemical-resistance, satisfaction of the markets' requirement for eco-friendly (halogen free).
| Item No. | Total Tape Thickness(μm) |
Adhesion (N/25mm) |
Short-term Heat Resistance (°C) |
Long-term Heat Resistance (°C) |
Recommended Substrate |
Features |
|---|---|---|---|---|---|---|
| A50125 HS | 25 | 10 | 240°C | 130°C | Metal, HSE Plastic |
High Performance High Shear |
| A5005 HS | 50 | 15 | 240°C | 130°C | ||
| A50125 HS | 125 | 18 | 240°C | 130°C | ||
| A5105 LE | 50 | 11 | 210°C | 130°C | LSE Plastic | Low Surface Energy Bonding |
| A51075 LE | 75 | 13 | 210°C | 110°C | ||
| A51125 LE | 125 | 16 | 210°C | 110°C | ||
| A5205 LM | 50 | 16 | 190°C | 110°C | Foam & Fabric |
High Tack |
| A52125 LM | 125 | 18 | 190°C | 110°C | ||
| A5220 LM | 200 | 22 | 190°C | 110°C | ||
| A55005 | 5 | 5 | 220°C | 120°C | General | Very Thin Acrylic |
| A5501 | 10 | 9 | 220°C | 120°C |
Fixing various components for batteries, electronic device,
automovile interior material, logo etc.
| Item No. | Total Tape Thickness(μm) |
PET Carrier Thickness (μm) |
Adhesion (N/25mm) |
Color | Recommended Substrate |
Features |
|---|---|---|---|---|---|---|
| T8003 HS | 30 | 12 | 10 | Transparent, Black |
Metal, HSE Plastic |
High Performance High Shear |
| T8005 HS | 50 | 12 | 12 | |||
| T8010 HS | 100 | 25 | 15 | |||
| T8020 HS | 200 | 50 | 20 | |||
| T8103 LE | 30 | 12 | 10 | Transparent, Black |
LSE Plastic | Low Surface Energy Bonding |
| T8105 LE | 50 | 12 | 12 | |||
| T8110 LE | 100 | 25 | 15 | |||
| T8120 LE | 200 | 50 | 23 | |||
| T8210 LM | 100 | 12 | 17 | Transparent | Foam & Fabric |
High Tack |
| T8220 LM | 20 | 25 | 28 |
Our foam tapes offer solutions of excellent adhesive strength and effective shock absorbing.
The foam made of acrylic, polyolefin and polyurethane.
| Item No. | Total Tape Thickness (mm) |
Adhesion (N/25mm) |
Type | Color | Features |
|---|---|---|---|---|---|
| 3025H | 0.25 | 24.6 | Self Stick | White, Grey | Conformable |
| 3040H | 0.4 | 26.7 | Self Stick | White, Grey | |
| 3060 | 0.6 | 42.5 | Self Stick | White, Grey | |
| 3080 | 0.8 | 39.4 | Self Stick | White, Grey | |
| 3011W | 1.1 | 45.7 | Self Stick | White, Grey | General Purpose |
| 3015 | 1.5 | 39.4 | Self Stick | Grey | |
| 3020 | 2 | 42.6 | Self Stick | White, Grey | |
| 3002 | 0.2 | 34.5 | Acrylic | Black | |
| 3225B | 0.25 | 41.2 | Acrylic | White, Grey, Black | High Strength High Shear Damp Vibration Shock Resistance Design Flexibility |
| 3240W | 0.4 | 41.2 | Acrylic | White, Grey, Black | |
| 3260 | 0.6 | 53.2 | Acrylic | White, Grey, Black | |
| 3280 | 0.8 | 46.2 | Acrylic | White, Grey | |
| 3211 | 1.1 | 47.5 | Acrylic | White, Grey, Black | |
| 3215 | 1.5 | 45.1 | Acrylic | Grey | |
| 3220 | 2 | 49.5 | Acrylic | White, Grey | |
| 3250 | 0.5 | 47.5 | Acrylic | Transparent | Anti-yellowing |
| 3210 | 1 | 45.1 | Acrylic | Transparent |
This product is applied to interior/exterior surfaces such as automobile and electric/electronic goods. Acrylic adhesive is applied to PE foam which has strong water resistance, sound resistance, and elasticity capabilities. It has excellent durability and enables user to easily perform its work without interference.
| Item No. | Total Tape Thickness(μm) |
Adhesion (N/25mm) |
Adhesive | Heat Resistance (°C) |
Foam Density (kg/㎡) |
Features |
|---|---|---|---|---|---|---|
| 62200 | 200 | 16 | Acrylic | 120 | 0.4 | Conformable PE Foam Carrier Excellent Static Shear Adhesive Adapted Easy to Converting |
| 62300 | 300 | 18 | Acrylic | 120 | 0.3 | |
| 62400 | 400 | 20 | Acrylic | 120 | 0.3 | |
| 62500 | 500 | 21 | Acrylic | 120 | 0.2 | |
| 62800 | 800 | 22 | Acrylic | 120 | 0.18 | |
| 62900 | 900 | 23 | Acrylic | 120 | 0.1 |
It has an excellent adhesion strength, even if adhesion is so hard, it can use easier on LSE that are ABS, Plastic material, etc. It has high initial tack, good adhesion strength on the rounded surface, good heat-resistance and dynamic shear strength, and It can be widely appied to home, office, mobile phone and automotives industry, etc.
| Item No. | Total Tape Thickness (mm) |
Adhesion (N/25mm) |
Adhesive | Heat Resistance (°C) |
Features |
|---|---|---|---|---|---|
| 4228C | 80 | 17.1 | Acrylic | 60 | High Initial Tack Non-woven Tissue Carrier |
| 4221W | 100 | 16.4 | Acrylic | 80 | |
| 42214W | 140 | 23.5 | Acrylic | 100 | |
| 4222C | 200 | 20.5 | Acrylic | 120 | |
| 4211W | 100 | 18.6 | Acrylic | 60 | Foam Lamination Name Plate, Deco Panels |
| 42113W | 130 | 25.4 | Acrylic | 60 | |
| 42116W | 160 | 20.5 | Acrylic | 120 |
Coated with Acrylic adhesive to keep high adhesion inside and low adhesion outside. It shows difference in and out and it is easy to rework. This is an eco-friendly halogen-free treated product. It is available for fixing LCD displays and conjugating and fixing materials in PCB.
| Item No. | Total Tape Thickness (mm)/th> | Adhesion (N/25mm) |
Adhesive (N/25mm)(B) |
Color | Adhesive | Features |
|---|---|---|---|---|---|---|
| 8243AC | 30 | 0.5 | 3.9 | Transparent | Silicone / Acrylic | Differential Adhesive |
| 8245AC | 50 | 10.8 | 11.8 | Transparent | Silicone / Acrylic | |
| 8249AC | 90 | 9.8 | 11.8 | Transparent | Silicone / Acrylic | |
| 8241AC | 100 | 9.8 | 14.7 | Transparent | Silicone / Acrylic | |
| 82415AC | 150 | 11.8 | 29.4 | Transparent | Silicone / Acrylic | |
| 8242AC | 200 | 12.8 | 17.6 | Transparent | Silicone / Acrylic | |
| 8225DF | 50 | 0.4 | 14.7 | Black & White | Acrylic / Acrylic | Clean Removable |
| 8221DF | 100 | 4.4 | 28.4 | Black & White | Acrylic / Acrylic | |
| 82215DF | 150 | 4.4 | 29.3 | Black & White | Acrylic / Acrylic | |
| 8225DCF | 50 | 13.7 | 15.4 | Transparent | Acrylic / Acrylic |
